m908 User Manual, Rev. G
15 Manual Revision History
Manual Revision History
Rev. Description Date Initials
A Initial Release 9/30/2019 MBG
B Changed L-R Setup parameter information.
Edit Firmware update procedure
Update DB15 Connector Pin function table
Updated the Workflow Template table
10/9/2019 MBG
C Update RCU cable wiring diagram to show no GND connection
on pin 14.
Update ACU and RCU DB15 pin function table.
Update Ext Talkback gain range.
Update Talkback XLR Output Connector description,
Corrected references to unity gain in 5.3.4 and 6.3.14
Replace Room EQ screenshot in Setup>CR1, CR3, CR3
Update Digilink module option section.
10/11/2019 MBG
D Update Room EQ Q range specifications
Update User ABC Switch Setup to show downmix options.
Update Setup CR Outputs to explain Headphone CUE/CR EXT
routing conflicts.
Change Cue Unity Gain setting
10/26/2019 MBG
E Update max power consumption specs
Update CR1, CR2, CR3 Setup routing conflicts on CUE/CR EXT
with Headphones enabled.
Update Clock Status table to include PLL Lock status
Updated Level Indicator thresholds.
11/13/2019 MBG
F Add Direct Input Offset Mode details in section 5
Add GPIO Trigger mode to GPIO table.
Add GPIO Logic definitions to GPIO setup.
Add warnings to not turn of power when workflows are being
saved.
Fix CR Output hardware conflict table
11/26/2019 MBG
G Update Meter Routing flow diagram.
Update Direct Access Input Offset saving information.
Add Setup Input speaker icon color information.
Add ADC input routing drawing.
Add Control Room Output routing conflict information.
12/10/2019 MBG
