m908 User Manual, Rev. G
10 Positive(+) Positive(+) Positive(+)
23 Negative(-) Negative(-) Negative(-)
3
22 GND GND GND
21 Positive(+) Positive(+) Positive(+)
9 Negative(-) Negative(-) Negative(-)
4
8 GND GND GND
7 Positive(+) Positive(+) Positive(+)
20 Negative(-) Negative(-) Negative(-)
5
19 GND GND GND
18 Positive(+) Positive(+) Positive(+)
6 Negative(-) Negative(-) Negative(-)
6
5 GND GND GND
4 Positive(+) Positive(+) Positive(+)
17 Negative(-) Negative(-) Negative(-)
7
16 GND GND GND
15 Positive(+) Positive(+) Positive(+)
3 Negative(-) Negative(-) Negative(-)
8
2 GND GND GND
1 Positive(+) Positive(+) Positive(+)
14 Negative(-) Negative(-) Negative(-)
Note: For unbalanced output operation leave the Negative (-) pin open
