GSE Scale Systems - 189
Chapter 17 Truck Weighing Technical Reference Manual
17.13 Invoke a “Macro” From the Truck IN/OUT
Software
Macros tie all the capabilities of the unit together. The following is an example of how to invoke a macro from the
Truck IN/OUT software. A good background with macros and setpoints is necessary. This example (technique 1025) is
taken directly from the GSE Scale Systems’ Engineer’s Notebook. This publication is a collection of macro code
examples and techniques put together by the engineers at GSE. All examples are complete and pre-tested at GSE.
Contact GSE for more information on the Engineer’s Notebook.
The following example performs an accumulation of the net weight.
OBJECTIVE: Configure the unit to invoke a macro after the “out” weightment is
performed of a Truck IN/OUT operation. This technique will tie the
capabilities of the truck IN/OUT software with the unit’s macro
capabilities.
PROCEDURE: SET UNIT FOR TRUCK USE
720%s1%e P720.01 IDUSE: Truck
MACRO “0” (accumulate truck net wt.)
800%s%c%e P800.24 macro # 0
13,6%%+%e add
91%%s%e select
0%%e%e enter
%%s%e select
91,13%%C%e copy
SETPOINT “32”
8200%s1%e P8200.1 SPt32 Enbld (output)
SECTION - 17.12
Tare Stored Ticket:
Truck ID: 123
Stored Tare Wt: 8500 lb
(Recalled Tare Weight)
