GSE Scale Systems - 241
Chapter 23 Sample Scale (OPTION) Technical Reference Manual
Chapter 23 Sample Scale
(OPTION)
23.1 Sample Scale 2# Cell
(GSE Part#: 194503-00020)
The Model 574 can accommodate a 2 pound sample
scale into its enclosure for convenience of establishing
more accurate pieceweights.
Supplied as a standard item is the sample platter itself.
The loadcell will install directly beneath the platter.
This option must have the multi-scale card in order to
function. Refer to chapter 22 for more information on
the Multi-Scale card.
The following accessories for the 2# sample scale are
available from GSE:
Item#
GSE Part# Description
KIT 194503-00020 2# Cell (kit) does
not include the
multi-scale card.
CELL 154503-00020 2# Cell (load cell
only)
The following replacement spare parts for the 2# sample
scale are available from GSE:
Item#
GSE Part# Description
28-10-20669 Warning Label
8 37-30-28795 Cell mounting
bracket
37-40-287942 overload pin
9 44-60-29708 Suspension assembly
44-25-29575 Top support
44-25-29588 Load Plate
44-25-29660 Detail Platform
23.2 Contents of Sample-Scale Kit
(1) M4503 Load Cell 2 LB CAP. (GSE PN:
154503-00020)
(2) 5702-65-48Z1,M4 OVERSIZE WASHER
(GSE PN: 38-26-1310)
(2) M4-0.7X8MM, HEX HD,SEMS-SPT,ZP (GSE
PN: 38-26-8080)
(2) M4-0.7X12MM, HEX HD,SEMS-SPT,ZP
(GSE PN: 38-26-8120)
(1) USER,S MANUAL (DOCUMENTATION)
(GSE PN: 39-10-29295)
(1) COUNTING SCALE SUSPENSION (GSE PN:
44-25-29062)
(1) SHIELD, M4503 SAMPLE SCALE (GSE PN:
44-30-29279)
(1) FOAM RUBBER POSITIONING RING
(SUSPENSION CENTERING RING) (GSE
PN: 44-30-29413)
23.3 Load Cell Installation Procedure
Hardware installation procedure for SAMPLE SCALE
LOAD CELL: (refer to figure 36)
NOTE: Some steps
might require the unit to be
positioned on its side during installation. Be
careful when doing so.
1. Important: Make sure the multi-scale
option card is installed before adding the
option load cell. If a third scale is to be added
to the system, make sure the third scale board
is installed before adding the option load cell.
Refer to the multi-scale card installation
documentation in chapter 22 of this manual.
2. The Option Load Cell is easily installed by
SECTION - 23.3
CAUTION:
This procedure should be performed by qualified
service personnel only! Hazardous voltages are
accessible within the instrument.
To Next Page
