Model 574 Programmable Counting System (PCS)
20 - GSE Scale Systems
The Chart below shows all the parameter selections in the 574 system. An Asterisk (*) next to a parameter indicates a
manufacturer default setting.
* = Manufacturer (GSE) Default Setting.
* = Factory Default Setting
PARAMETER # SELECTION DESCRIPTION
MULTI-SCALE
P101.00 Scl 1 Disbl Disable Scale 1
P101.01 Scl 1 Saved Disable Scale 1, Save Setup and
Calibration
P101.02 Scl 1 * Enbld Enable Scale 1
P102.00 Scl 2 through Same as parameter P101
P103.00 Scl 3 for Scales 2 and 3.
CELL EXCITATION
P105.00 Exc AC * AC excitation Selects the type of load cell excitation P105.01
Exc DC DC excitation voltage.
BASIC INSTRUMENT
SETUP (SCALE 1)
P110.- - F.S.= XXX.XXX Full Scale Capacity of Platform
* 100.00 Load Cell.
P111.00 1 div 00001 Set Count-By and Decimal Point
P111.01 00002
P111.02 00005
P111.03 .0001
P111.04 .0002
P111.05 .0005
P111.06 .001
P111.07 .002
P111.08 .005
P111.09 * .01
P111.10 .02
P111.11 .05
P111.12 .1
P111.13 .2
P111.14 .5
P111.15 1.
P111.16 2.
P111.17 5.
thru
P111.23 500.
To Next Page
