Model 574 Programmable Counting System (PCS)
44 - GSE Scale Systems
PARAMETER # SELECTION DESCRIPTION
INPUT INTERPRETER
P900.00 RxInp Disbl Formats data received through the
serial port
P901.00 RxTrm Formats data sent through the
P901.10 RxTrm <LF> Line Feed
serial port
P910.00 RxTyp Unusd Unused
P910.01 Char Character
P910.02 Line Line
P920 through P980 Input specifications #2 through
#8
CUSTOM
TRANSMIT SETUP
P1000 XXXXX XXXXX Enter information for 1st
Custom Transmit.
P2000 XXXXX XXXXX Enter information for 2nd
Custom Transmit.
P3000 XXXXX XXXXX Enter information for 3rd
Custom Transmit.
P4000 XXXXX XXXXX Enter information for 4th
Custom Transmit.
SETPOINT SETUP (RELAY OUTPUTS ARE NOT AVAILABLE ON THE 574, CONTACT GSE)
The setup of setpoints is covered more completely in Chapter XX21. Some of the parameters listed below may
or may not appear depending upon previous selections. Since there are 32 setpoints within the System and the
programming for each is the same with the exception of the parameter numbers, we have included only the
parameters for Setpoint #1. The parameter numbers begin with P5100 for Setpoint #1 up through P8200 for
Setpoint #32. (M574 utilizes the software capabilities of the setpoint features only.)
P5100.0 SPt 1 * Disbl Enable / Disable setpoint
operation
P5100.1 Outpt Enable / Disable setpoint
output
P5100.2 Input Enable / Disable setpoint
input
P5110.0 Activ * Above Output active if weight is
above target value
P5110.1 Below Output active if weight is
below target value.
