Model 574 Programmable Counting System (PCS)
56 - GSE Scale Systems
PARAMETER # INFORMATION DESCRIPTION
P61114. Gain Adj2 X Compensation for the coarse gain
(P61106) Any combination of P61113
thru 61116 will be used to achieve the
value of P61106.
P61115. Gain Adj4 X Compensation for the coarse gain
(P61106) Any combination of P61113
thru 61116 will be used to achieve the
value of P61106.
P61116. Gain Adj8 X Compensation for the coarse gain
(P61106) Any combination of P61113
thru 61116 will be used to achieve the
value of P61106.
P61117. AIN1 NROff X Analog IN: This parameter
compensates for the non-ratiometric
offset.
P61118. AIN2 NROff X Analog IN: This parameter
compensates for the non-ratiometric
offset.
P61119. AIN4 NROff X Analog IN: This parameter
compensates for the non-ratiometric
offset.
P61120. AIN8 NROff X Analog IN: This parameter
compensates for the non-ratiometric
offset.
P61121. VREF NROff X Compensation of Reference Voltage.
If the sense leads are shorted, then the
reference voltage should be zero. If
the leads are not shorted, this factor
will compensate for the error.
P61130. -CAL- WGHT1 Displays weight used
for the first cal point of
the Multi-Point
Linearization feature (if
enabled).
