Windsor 500 User Manual - Issue C
User Menus
Menu Restrictions
The display which appears on the Keypad LCD when a user logs on to the system will depend on the
authority allocated to the user, which Keypad is used, the set condition of the area, any other Keypad activity,
and any time restrictions governed by the event programmer.
Menu Format
0=Reset 2=Set
5=Eng 6=Text.......
Where a choice of functions is offered to the user, they are shown on the display
preceded by a one digit number. To select a function the user must enter the
appropriate number at the Keypad. Where the complete user choice cannot be
shown on the display, a series of dots will appear after the last choice to indicate that
a further selection is available.
Pressing the ▼ button will display other choices available to the user.
7=Light 8=PIN
↵=Next Page
Where the choice of functions exceeds ten, the user can select the ‘Next Page’ of
functions by pressing the ↵ button when shown.
Quitting a Menu
0=Reset 2=Set
5=Eng 6=Text.......
When a user has selected a function from page 1 or 2 of the ‘User Options Menu’, and
wishes to leave the selection, pressing ‘Quit’ will return the display to the previous
menu.
↵=Confirm LogOff
Pressing ‘Quit’ when the ‘User Options Menu’ is displayed will display the option to quit
from the ‘User Options Menu’ completely. Press ‘↵‘ to confirm log off, or ‘Quit’ to
return to the ‘User Option Menu’
Company-Name
Enter-
Help Menu
User-04
J. Smith -Off
When the system requires the user to input information (e.g. ‘Authority’), pressing the
‘Help’ button will display the limits, options, or values available.
0=Off 1=Manager
2=Ordinary..........-
Again, where more options are available than can be displayed, the last option is
followed by dots to indicate that options are available. Press the ▼ button to display
other options. Pressing the ‘Help’ button at any other time will display ‘Not Available -
Key Not Used’.
▼
Quit
↵
Help
