Guardall Windsor 500 - Modifying Light Controls; General Light Control; Light Zone Operations

Windsor 500 User Manual - Issue C
-
38
-
Modifying Light Controls
General
The engineer on installation normally programs the operation of security lighting on the Windsor. However, a
user with ’Manager’ authority can modify and test the lighting zones as follows:-
(a) Modify the ’On’ duration when the light zone is automatically triggered.
(b) Modify the 'On' and 'Off times for ‘Timer Control'.
(c) Modify the 'Off’ time after dusk.
(d) Manually operate the lighting zones.
(e) Test the lighting zones.
2=Set 4=Test
5=Eng 6=Text......
1. Log on to a system Keypad using a ‘Manager' PIN code. The user options will be
displayed
7=Light 8=PIN
↵ = Next Page
2. Select option 7,'Light'
Light Zone
Number-
3. The display will prompt for the required light zone number. Enter a one-digit zone
number (1 to 4).
3=Off Time
5=Manual 6=Test
4. The 'Light Zone' menu will be displayed.
Operations
In Operations the light zone can be configured for two modes of operation, and these are ‘Alarm’ and/or
‘Set/Unset’. If alarm is configured, the light zone will be active for the programmable time if an alarm occurs.
If set/unset is configured, the light zone will be active for the programmed time if the area is set or unset.
Light Zone - 1
Auto Time-00
1. Select 1 from the 'Light Zone' menu
Light Zone - 1
Auto Time - 03....
2. The display will show the existing programmed 'On' duration for the selected light
zone. This is called the ‘Auto Time’. The existing duration will be flashing.
Light Zone - 1
Alarm Off.........
3. To change the duration, enter a new two-digit duration in the range 01 to 99
minutes.
4. To have a light zone active when an alarm occurs select 1 to program alarm 'On'.
Light Zone - 1
Alarm On.............
5. Light zone 1 is now on for alarm activations.
6. In the same manner, to have a light zone active when an area sets/unsets, select ‘1’.
Light Zone - 1
Set/Uns On.......
7. Selection of 1 will program Set/Unset ‘On’.
8. Press 'Quit'.
1=Operations
2=On Time
9. The display will return to the Light Zones menu.
7
1
1
1
1
Quit
