Windsor 500 User Manual - Issue C
24Hr Test
All Tested
4. When the user returns to the Keypad, any circuits which have not been tested will be
shown on the Keypad display. On completion of tests the display will inform you that all
tests are complete.
1=PA 3=Detector
5. The user should test all required circuits before the display will return to the ’Unset
Test Functions’ menu. The ’24 Hr’ function will be removed from the menu.
Note: The user can quit from the test function by pressing the ’Quit’ button on the Keypad, however, any
circuits not tested will be recorded in the system event log.
WARNING:- Should the 24Hr option be configured for ‘fire’ and the alarm circuit is not cleared before
completing all tests, (or before the time limit expires), an actual alarm condition will occur. Please ensure
that a successfully tested fire circuit is cleared before moving on.
Detector Test
Detector Test
Busy Please Wait
1. Selecting 3 from the ’Unset Test Function’ menu will permit the user to undertake a
manual test of all detectors programmed for ‘Detector Test'.
2. The response of each detector is automatically tested and the result of the test
displayed on the area Keypad display, e.g., 'Detector Test OK' or 'Detector Test Failed'.
Detector Test OK
Press any Key
3. This test is in addition to the 'Automatic Detector Test' programmed to operate daily
at a pre-set time. The manual and automatic detector test will operate for a pre-
programmed test period. All detector test results are recorded in the system event log.
Detector Failed
Press any Key
4.The result of the 'Detector Test' will be displayed on the area Keypad LCD, as
follows:
Detector Test OK All detectors tested.
Detector Test Failed One or more detectors failed to respond
Communications Test
A 'Manager' or ‘Ordinary User' or 'Engineer' can test the operation of the system communicator(s) if fitted as
follows:
4=Comms
1. Select 4 from the 'Test Functions' menu
Primary
Busy Please Wait
2. The communicator test will begin. The duration of the test will depend on the type
of communication device installed.
1=Sounders
2=Walk Test
3. Press 'Quit to return to the 'Test Functions Menu'
4=Test 5=Eng
6=Text......
4. Press 'Quit' to return to the 'User Options Menu'
3
4
Quit
