Windsor 500 User Manual - Issue C
2=Walk Test
3=Unset Test
1. Select 3 from the ’Test Functions’ menu.
1=PA 2=24Hr
3=Detector
2. The ’Unset Test Functions’ menu is displayed. Select required unset test function.
Panic Alarm Testing
1=PA 2=24Hr
3=Detector
1. Selecting 1 from the ’Unset Test Function’ menu will permit the user to manually test
all panic alarm buttons without causing a full alarm condition or transmitting an alarm
signal to the Communications centre.
Cct 6
Not Tested
2. The display will scroll through the circuits not tested. When all PA circuits have been
activated, the display will indicate 'All Tested’ and automatically return to the 'Unset
Test Function Menu', with PA removed. However, for security reasons, a limiting timer
is incorporated into the PA test function which will automatically discontinue the test
condition after a period of 20 minutes, thereby ensuring that the user cannot leave the
system in this condition beyond the pre-set time. An audible warning is emitted when
only 5 minutes of the test time remains. All PA button tests are recorded in the system
event log.
PA Test
All Tested
3. Pressing a Panic Alarm button during the 20 minute PA Test period will activate the
internal sounder(s) only and display the ‘All Tested’ message on the screen. Once the
last system is tested the display will revert back to the ‘Unset Test Functions’ menu
with the PA Test function removed.
4. Pressing the 'Quit' button on the Keypad at any time during the 20 minute PA Test
period will return the PA circuits to the normal 24 hour monitoring mode and will return
the display to the 'Unset Test Functions' menu with the PA Test function removed.
2=24Hr
3=Detector
Cct-1 Alarm
1=Temp By-pass
Note:- Should the PA remain set after test, the system will allow a temporary by-pass.
Either clear the alarm manually, or initiate the Temp By-pass by pressing 1 on the
keypad.
24 Hr Test
Selecting 2 from the 'Unset Test Function' menu will permit the user to test all circuits which are armed
whether the system is set or unset (24 hour monitoring circuits), with the exception of panic alarm circuits.
This will not cause a full alarm condition or transmitting an alarm signal to the alarm company central station.
As with Panic Alarm testing, a 20-minute limiting timer is incorporated into the 24 Hr test function, ensuring
the engineer/user cannot leave the system in this condition. To carry out a 24 hour circuit test proceed as
follows:
2=24Hr
3=Detector
1. Select 2 from the 'Unset Test Function' menu
Fire Door
Not Tested
2. The display will show the first circuit which has not been tested, e.g., ‘Fire Door'.
Secure Store
Not Tested
3. As each circuit is activated during testing, the area sounder will emit an alarm tone
while the circuit is open or activated and will cease when the circuit is closed or
cleared. When a circuit has been successfully tested, it is removed from the circuits
'Not Tested'.
3
Quit
2
