Guardall Windsor 500 - Timed Control; Dusk Control

Windsor 500 User Manual - Issue C
-
39
-
Timed Control
Timed control enables a light zone to be programmed to switch on and off at pre-programmed times. This
gives a capability to provide courtesy lighting at necessary times e.g. light a driveway when people are
coming home.
On Time Set to
00:00
1. Select 2 from the ’Light Zones’ menu. The display will show the current on time. A
time of 00:00 means that this option is disabled.
On Time
HH:MM
2. Press ’↵' to change the current on time. The display will prompt for a new ‘on’ time.
On Time Set to
22:50
3. Enter a new ‘on’ time in 24 hour format. The display will show the new ‘on’ time.
2=On Time
3=Off Time
4. Press 'Quit' to return to the light zone menu.
Off Time Set to
00:00
5. Select 3 from the light zones menu. The display will show the current ‘off’ time.
Off Time
HH:MM
6. Press '↵‘ to change the current ‘off’ time. The display will prompt for a new ‘off’ time
.
On Time Set to
07:00
7. Enter a new ‘off’ time in 24 hour format.
3=Off Time
4=Dusk Time
8. Press 'Quit' to return to the light control menu.
Dusk Control
Dusk Time Set to
07:00
If 'Dusk Control' is 'On' for a light zone when programmed by the engineer the lights will
be turned on automatically at dusk, and turned off at the programmed 'Off' time. To
view or edit the 'Dusk Control' function, proceed as follows:
3=Off Time
4=Dusk Time
1. Select 4 from the 'Light Zones' menu.
Dusk Time Set to
07:00
2. The display will show the current 'Dusk time’.
Dusk Time
Enter HH:MM
3. Press 'Enter’ to change the current 'Dusk time’.
4. Enter a new 'Dusk time’ (HH:MM), e.g., 17:00. A time entered of 00:00 will turn off
this feature
Dusk Time Set to
19:00
5. When entered, screen will show this message. Press enter to revert to Light menu.
2
↵
Quit
3
↵
4
↵
