Windsor 500 User Manual - Issue C
tone will operate until the ’Entry/Exit’ is closed or the ’Exit Time’ has expired. The user must leave the area
by the prescribed ’Exit Route’. If a user deviates from the prescribed ’Exit Route’ during exit, the exit tone will
change to a pulsing tone while the ’Non Exit Route Circuit’ is open or activated.
Keyswitch Setting
A Keyswitch may be fitted and used to set and unset an area of the system. The Keyswitch (if fitted) is used
to set and unset the area only and does not permit the user access to any other functions. When an area is
set (or unset) using a Keyswitch, the event is recorded in the event log as 'Key Set Req'. User number ‘0’' is
attributed to this operation because the action is performed by the system itself.
Communicator Set Acknowledgement
Your system may incorporate 'Return Path Signalling', whereby an Acknowledgement signal will be sent from
the central station to acknowledge that they have received the 'Set' signal. This 'Acknowledge' signal may be
used to activate a bleeper, the external strobe light or another signalling device for a short period. The user
should ensure that the 'Return Path Signal' has been received after the system has set.
(Note: Only available if more than 2 areas are configured and the option has been enabled by the engineer)
Home Set
If the system has been Part Set and the set area activates, the bell delay and communicator will be cancelled
giving a "bell only" system.
