Windsor 500 User Manual - Issue C
Unsetting After an Alarm
Unset
Public Area
If an alarm condition has occurred during the ’Set’ period, the area sounder, audible
alarm and/or strobe may be operating. The action of unsetting the area (or system) will
cancel all warning devices. If the area has been programmed for ‘Auto Reset', the
warning devices may have automatically cancelled and the area reset.
Alarm
Cct 34
If the area incorporates an entry route, a pulsed tone emitted from the internal
sounder(s) when the entry door is opened will indicate that an alarm has occurred
during the set period.
Alarm
Cct 36
1. When the user has unset the area, the most recent event in the area log will be
displayed on the area Keypad. If more than one event has occurred during the 'Set'
period, the display will automatically scroll through the list of events in the area log.
Note: If unsetting from a Keypoint and an alarm has occurred during the 'Set Period'
the 'Message' LED will be illuminated. Proceed to an area Keypad to view the area
event log.
↵ = Reset
2. The display will then prompt for the user to 'Reset' the area by pressing the '↵'
button.
2=Set 4=Test
5=Eng 6=Text......
3. If all circuits are clear, the area will reset and the display will show the 'User Options
Menu'. If all circuits are not clear, the display will continue to show the area log.
Tel:XXXXXXXXXX
Ref:XXXXXX
4. If the area is configured for ‘Engineer Reset', the site number and service telephone
number will be displayed after the last alarm event has been viewed. The user must
contact the alarm company to report the condition. If the condition(s) causing the
alarm is clear, the user may 'Reset' the area. However, if programmed for ‘Engineer
Reset', the user will be unable to 'Set' the area until an engineer attends the premises.
5. If there are events in the area alarm log the 'Reset' option is displayed on the 'User
Options Menu' when '↵' is pressed.
0=Reset 2=Set
3=Log 4=Test
↵
