Windsor 500 User Manual - Issue C
Testing The Strobe
3=Strobe
1. Select 3 from the sounder menu to test the strobe light(s)
Strobe On
Seconds Left-05
2. The strobe light(s) for the area (or system) will be activated for the pre-programmed
test period (max. 60 seconds). The remaining test time is shown on the Keypad
display.
Note: To stop the strobe test, press any button on the Keypad.
1=Sounder
2=Audio
3. When the strobe test is completed or stopped, the display will return to the
’Sounder Menu’ with the ’Strobe’ option removed. If all tests have been performed, the
display will automatically return to the ’Test Functions Menu’.
2=Walk Test
3=Unset Test
4. Press ’Quit’ to return to the ’Test Functions Menu’.
Walk Test
Selecting option 2 from the ’Test Function’ menu will enable the user to carry out a walk test of the area (or
system). The user may carry out an 'Automatic' walk test or ‘Manual' walk test. The 'Automatic' walk test will
require the user to only test circuits which have not been activated since the area was unset or last tested
(whichever is the most recent). The 'Manual' walk test will require the user to test all circuits. The 'Walk Test'
function cannot test PA circuits, Excalibur lighting circuits, or circuits with an unset response.
1=Sounders
2=Walk Test
1. Select 2 from the 'Test Functions' menu.
1=Auto 2=Manual
2. The display will show a choice between 'Automatic' or 'Manual' walk testing. Select
as required, (1 or 2).
Back Door
Not Tested
3. The display will show the first circuit which has not been tested, e.g., ‘Back Door'.
Canteen PIR
Not Tested
4. As each circuit is activated during walk testing, the Keypad bleeper will emit a 3
second test tone. When a circuit has been successfully tested, it is removed from
the circuits 'Not Tested'.
3=Unset Test
4=Comm Test
5 When the user returns to the Keypad, any circuits which have not been tested will be
shown on the Keypad display. The user must test all required circuits before the
display will return to the 'Test Functions' menu. The 'Walk Test' function will be
removed from the menu.
Note: The user can quit from the walk test function by pressing the 'Quit' button on the Keypad, however any
circuits not tested will be recorded in the system event log.
Unset Test Functions
The ‘Unset Test' can be selected from the 'Test Functions' menu. This test enables the user to test panic
alarm circuits and all 24 hour monitoring circuits. A 'Manager', 'Engineer' or 'Ordinary User' can also carry out
a manual detector response test of all detector circuits which have been programmed for 'Detector Test'.
This test is in addition to an automatic 'Detector Test' which is carried out daily at a pre-programmed time.
