Windsor 500 User Manual - Issue C
Bypassing Circuits or Groups
Any circuits which have been programmed as ’By-passable’ can be bypassed by an ’Engineer’, ’Manager’ or
‘Ordinary User', providing they are authorised to do so, when the area is set. Bypassed circuits or groups will
be automatically re-instated when the system is unset, providing doing so will not cause an alarm condition.
Any circuits in any area which are already set cannot be bypassed.
A bypass limit may be programmed to limit the number of circuits that can be bypassed at any one time. To
bypass a circuit or group, proceed as follows:
2=Set 4=Test
5=Eng 6=Text.....
1. Log on using a ‘Manager’', 'Ordinary User' PIN code
7=Light 8=PIN
9=Bypass........
2. The user options are displayed.
3. Select '9' from the 'User Options Menu:. You may require to press the ▼ button to
display option '9'.
1=Circuit
2=Group
4. The choice of bypassing either groups or circuits is displayed. Select 1 to bypass a
circuit or 2 to bypass a group.
Circuit Number
5. The display will prompt for the circuit or group number to be bypassed. If a circuit is
to be bypassed, enter a circuit number (01 to 128). If a group has to be bypassed,
enter a one digit group number (1 to 6).
Loading Bay
Bypassed
6. The display will show the text descriptor for the circuit or group selected, together
with the condition of the circuit or group after selecting bypass (e.g., ’By-passed',
'Normal', or ‘Active').
Circuit Number
-
7. The display will prompt for another bypass circuit or group number.
1=Circuit
2=Group
8. Enter another circuit or group number to be bypassed or press 'Quit' to return to the
choice of bypassing either groups or circuits.
9=Bypass
↵ = Next Page
9. Repeat the process or press 'Quit' to return to the 'User Options Menu'
9
Quit
