GW Instek PSU Series Programming Manual

REMOTE CONTROL
113
:SYSTem:CONFigure:OUTPut:EXTernal:MODE
Set
Query
Description
Sets the logic used to turn the output on or off
when using an external contact. This is the
equivalent to the F-94 (External Output Logic)
power on configuration settings.
Note
The setting will only be valid after the power has been
cycled.
Syntax
Return Syntax
:SYSTem:CONFigure:OUTPut:EXTernal:MODE
{<NR1>|LOW|HIGH}
:SYSTem:CONFigure:OUTPut:EXTernal:MODE?
Parameter
HIGH | 0
Active high
LOW | 1
Active low
Return Parameter
<NR1>
Returns the logic setting.
Example
SYST:CONF:OUTP:EXT:MODE 0
SYST:REB
Set active high for the logic for the external analog
control contact and reboot the unit to active the
setting.
:SYSTem:CONFigure:OUTPut:EXTernal[:STATe]
Set
Query
Description
Sets whether the output will be turned on or off
externally. By default this setting is turned off.
This is the equivalent to the F-98 (External Output
Control Function) power on configuration
settings.
Note
The setting will only be valid after the power has been
cycled.
Syntax
Return Syntax
:SYSTem:CONFigure:OUTPut:EXTernal[:STATe]
{<bool>|OFF|ON}
:SYSTem:CONFigure:OUTPut:EXTernal[:STATe]?
Parameter
ON | 1
External control is performed.
