REMOTE CONTROL
81
Return parameter
<NR1>,<NR1>
0~1073741823, 0~30
(1073741823=2^30-1)
First value:
Each bit of the binary value
corresponds to a unit from 0 to 30
(LSB to MSB). The bit will be set to
1 when the corresponding unit is
on-line.
Second value:
This value represents the master
address.
Example
:INST:STAT?
33,0
33=0b100001
The units at address 0 and address 5 are on-line.
0
Master device's address is 0.
:INSTrument:DISPlay
Set
Description
Displays information (configured address) for all
slave units when using the Multi-Drop mode.
Syntax
:INSTrument:DISPlay
Example
:INST:DISP
