PSU Series Programming Manual
28
0~1.667Ω (PSU 50-30)
0~2.400Ω (PSU 60-25)
0~4.210Ω (PSU 80-19)
0~6.667Ω (PSU 100-15)
0~15.00Ω (PSU 150-10)
0~60.00Ω (PSU 300-5)
0~105.3Ω (PSU 400-3.8)
0~230.8Ω (PSU 600-2.6)
Bleeder circuit control
F-09
0 = OFF, 1 = ON, 2 = AUTO
Buzzer ON/OFF control
F-10
0 = OFF, 1 = ON
OCP Delay Time
F-12
0.1 ~ 2.0 sec
Current Setting Limit
(I-Limit)
F-13
0 = OFF, 1 = ON
Voltage Setting Limit
(V-Limit)
F-14
0 = OFF, 1 = ON
Display memory
parameter when recalling
(M1, M2, M3)
F-15
0 = OFF, 1 = ON
Auto Calibration Parallel
Control
F-16
0 = Disable, 1 = Enable, 2 = Execute
Parallel Calibration and set to Enable.
Note: Must be a short between each
unit before starting.
Measurement Average
Setting
F-17
0 = Low, 1 = Middle, 2 = High
Alarm Recovery and
Output Status
F-18
0 = Safe Mode, 1 = Force Mode
Lock Mode
F-19
0:Lock Panel, Allow Output OFF
1:Lock Panel, Allow Output ON/OFF
USB/GPIB settings
Show front panel USB
status
F-20
0 = None, 1 = Mass Storage
Show rear panel USB
status
F-21
0 = None, 1 = Linking to PC
Setup rear USB Speed
F-22
0 = Disable USB, 1 = Full Speed,
2 = Auto Detect Speed
GPIB Address
F-23
0 ~ 30
GPIB Enable/Disable
F-24
0 = Disable GPIB, 1 = Enable GPIB
Show GPIB available
status
F-25
0 = No GPIB, 1 = GPIB is available
SCPI Emulation
F-26
0 = GW Instek, 1 = TDK GEN, 2 =
