H3C S3100V2-52TP User Manual

96
To do… Use the command… Remarks
Configure the current port
as the monitor port
[ mirroring-group group-id ]
monitor-port
Required
By default, a port does not serve as the monitor
port for any remote destination group.
NOTE:
• A mirroring group contains only one monitor port.
• To make sure that the mirroring function works properly, do not enable the spanning tree feature on the
monitor port.
• H3C recommends you use a monitor port only for port mirroring. This is to make sure that the data
monitorin
g
device receives and analyzes only the mirrored traffic rather than a mix of mirrored traffic
and normally forwarded traffic.
• You cannot configure the monitor port in a mirroring group as a port in a RRPP ring.
Configuring the remote probe VLAN for the remote destination group
Follow these steps to configure the remote probe VLAN for the remote destination group:
To do… Use the command… Remarks
Enter system view system-view —
Configure the remote
probe VLAN
mirroring-group group-id
remote-probe vlan rprobe-vlan-id
Required
By default, no remote probe VLAN is
configured for a remote destination group.
NOTE:
• A VLAN can serve for only one mirroring group.
• When a VLAN is configured as a remote probe VLAN, use the remote probe VLAN for port mirrorin
g
exclusively. Do not configure a VLAN interface for the VLAN or configure any other features for the
VLAN.
• When a VLAN is configured as a remote probe VLAN, you must remove the remote probe VLAN
configuration before deleting the VLAN.
• When you remove the configuration of a remote probe VLAN, an active mirroring group becomes
inactive.
Assigning the monitor port to the remote probe VLAN
Follow these steps to assign the monitor port to the remote probe VLAN:
To do… Use the command… Remarks
Enter system view system-view —
Enter the interface view of the monitor
port
interface interface-type interface-number —
For an access port port access vlan vlan-id
For a trunk port port trunk permit vlan vlan-id
Assign the port
to the probe
VLAN
For a hybrid port port hybrid vlan vlan-id { tagged | untagged }
Required
Use one of the
commands
