Technical Data
19
4 Technical Data
4.1 Device General Specifications
Name
Value
Control Power
85V - 264V, 50/60 Hz
User Test Storage
Unlimited
Remote Interface
Ethernet RJ45
Display
7" / 800x480 / 24bit with touch-screen
External Trigger Input
5V TTL
Dimensions (W x H x D)
19" / 4U(45 x 18 x 49 cm)
Weight
30kg
USB
for USB memory stick
AUX Interface
D-sub 37p for external CDN, external transformer etc.
Synch Input
BNC, 10V – 264V AC
External Start / Stop Input
5V TTL, starts / stops predefined test sequence
Analog Output
0 – 10V, for use with external
Safety Circuit
stops the test when unlocked
4.2 Test Technical specifications
4.2.1 Surge
IEC / EN 61000-4-5 Edition 3 Surge Combination Wave
Name
Value
Output Voltage
0.2 – 7.0kV ±10%
Voltage Rise Time
1.2us ±30%
Voltage Duration
50us ±20%
Polarity
pos / neg / alternate
Output Impedance
2 Ohms
Phase Sync
0 – 359°with 1°steps or asynchronous mode
Counter preselect
1 – 1000 - Infinite
