Haefely AXOS - Burst Test Specifications

Technical Data
21
Front time OCV
10 µs ±30%
Decay time OCV
700 µs ±20%
Front time SCC
5 µs ± 20%
Decay time SCC
320 µs ± 20%
Source Impedance /
coupling
15 Ohm x 1
40 Ohm x 4
40 Ohm gas arresters x 4
Polarity
Positive / negative / alternate
Weight
10 kG
Dimensions (W x H x D)
19" / 4U
(45 x 18 x 49 cm)
Outputs
4mm banana socket
4.2.4 Burst
IEC / EN 61000-4-4 Edition 3 EFT / Burst
Name
Value
Output Voltage
0.2 – 5.0kV ±10% at
coaxial output
Polarity
pos / neg / alternate
Output Impedance
50 Ohms
Rise Time
5ns ±30%
Impulse Duration
50ns ±30% at 50 Ohm
50ns –15 +100ns
at 1000 Ohm
Burst Mode
normal continuous real
random
Spike Frequency
1Hz – 1MHz
Burst Duration
10us – 1s
Burst Period
1ms – 10s
Test Time
1s– 1000 minutes
Trigger
automatic manual
external trigger input
Integrated Single Phase Coupling /
Decoupling Network
264V AC / 16A
220V DC / 10A
