Haefely AXOS - Ring Wave Test Specifications (Axos Only); Telecom Wave Test Specifications (Axos Only)

20
Technical Data
Counter
100000
Peak Voltage Monitor
BNC output: 1000:1 , Display: 3 Digits
Output Current
0.1 – 3.5kA ±10%
Current Rise Time
8us ±20%
Current Duration
20us ±20%
Integrated Single Phase CDN
264V AC / 16A
220V DC / 10A
Impulse Trigger
automatic 2s – 100 minutes manual
external trigger input
Peak Current Monitor
BNC output: 1kA/V Display: 3 Digits
4.2.2 Ring Wave (Axos
8
Only)
IEC / EN 61000-4-12 Edition 3 & ANSI/IEEE C62.41 Ring Wave
Name
Value
Max. Voltage
0.2 – 7.0kV ±10%
Frequency
100 kHz
Rise time OC
5 µs
Rise time SC
1 µs
Impedance
12 Ohm, 30 Ohm
Peak Voltage Monitor
BNC output: 1000:1
Display: 3 Digits
Repetition rate
Up to 30 pulses /min
Polarity
Positive / negative / alternate
Floating output
Max. 460 V/AC
Phase sync accuracy
± 1°
Damping rate
0,4<peak1/peak2<1,1
Peak Current
Monitor
BNC output: 1kA/V
Display: 3 Digits
4.2.3 Telecom Wave (Axos
8
Only)
IEC / EN 61000-4-5 Edition 3 Telecom Wave /ITU K.20, K.21, K. 44, K. 45 (external TW 8 module)
Name
Value
Output Voltage
0.2 – 7.0kV ±10%
