be disconnected. The current transformer from capture 15.2.2 is for the verification
necessary.
7.2.3 SURGE MENU
Test requirements must be achieved by the user according to the IEC 61000-4-5 norm. The safety
standards as written in Table 1-1 must be unconditionally fulfilled, when operating the AXOS
8
.
In the next step, the user selects either the pre-compliance or the standard operation mode. The
Figure 7-3: Surge Standard mode and Figure 7-4: Surge pre-compliance mode reflects either of
the appliance modes. As seen by pressing on each particular function parameter a pink bow
comes up and the definition of the function gets displayed.
Figure 7-3: Surge Standard mode
When pressing the “home” button the user gets transferred automatically to the start menu.
In the Figure 7-4: Surge pre-compliance mode it is shown the use of the pre-compliance mode.
Indeed, every parameter can be changed by simply pressing on the black bows next to the value.
Furthermore, it can be changed between direct and line output. All testing parameters can be
changed while the generator is operating.
Figure 7-4: Surge pre-compliance mode
