5 Assembling and
Installation Guide
5.1 System Installation and
Installation Area
During transport AXOS8 may be subjected to excessive shocks and vibrations, even though every
care is taken by HAEFELY AG to provide suitable packaging. Before operating the unit, check for
signs of mechanical damage. Damaged packing cases may by a sign of transport damage.
Damage caused in transit must be reported to the shipping agent immediately.
5.1.1 Hardware Installation
All safety measures must be followed, as described in corresponding chapter “Safety”.
5.1.2 Ground connection
The "Earth Stud" on the back panel must always be connected to a solid earth before the "EUT
Supply Input" is connected to power source. Cross section of connection must be at least 2.5mm
squared
5.1.3 EUT inputs
The "EUT Supply Input" on the back is the connection to the integrated single-phase CDN, which
can be used up to 16A / 264V.
There are three banana-plugs (stackable) delivered with the standard accessories set:
- black: line conductor
- blue: neutral conductor
- green/yellow: protection earth conductor
These banana plugs shall be mounted on a suitable connection cable.
The EUT Supply Input must be connected to power lines which are protected by a line safety
switch equal or less 16A rated current and characteristic B or C.
