Technical Data
4.2.5 Voltage Dips & Interrupts
IEC / EN 61000-4-11 Edition 2 and IEC / EN 61000-4-29 Dips & Interrupts (external DIP 116
module)
Name
Value
Max. Voltage
264V AC/DC
Max. Current
16A AC/DC continuous 20A for 5s
40A for 3s
500A inrush Current
Trigger
automatic manual
external trigger input
Interrupt Dip Level
0%
0% – 99% with external voltage source
RMS Voltage Monitor
BNC Output: 100:1
Display: 4 Digits
Interrupt Time
0.5 period – 800 periods 100us – 1000 minutes
Interval Time
1 period – 800 periods synch
100us – 1000 minutes async
Test Time
1s – 1000 minutes Infinite
Phase Sync
0 – 359° 16 / 40 / 50 / 60 Hz
asynchronous Mode
RMS Current Monitor
BNC Output: 10A/V Display: 4 Digits
4.2.6 Integrated single-phase CDN
AXOS provides an integrated single-phase coupling / decoupling network for Burst, Surge tests
and Ring Wave.
It is protected against over-current by an integrated protection circuit. Current limit can be selected
between 1A to 16A in the PROPERTIES menu.
The integrated CDN may be used with AC or with DC power lines.
The input of the integrated CDN (i.e. EUT Supply Input) must be connected to power lines which
are protected by a line safety switch equal or less 16A rated current and characteristic B or C.
4.3 Standards
The AXOS8 fulfils the requirements of IEC 61010-1.Product description
