4
1. Ethernet 4-33
Network Communications
Read Bits from PLC Memory
int HKEtn_ReadPlcBitMemory(int *lpOnFlag,int DeviceType,DWORD addr,int
BitNo,char *lpAddr)
This function is retained until PLC data is transferred from the V7 series.
• Parameters
*IpOnFlag Returns the bit status. 0: OFF 1: ON
DeviceType Address of the device to be read (Refer to “Chapter 5 Connection to
PLCs.”)
addr Top memory address to be read
For YOKOGAWA or YASKAWA PLCs, specify a number “−1” for the
address (addr).
Example: D400 → 399 D25 → 24
BitNo Bit number to be read
Example 1: When accessing to D20-05 of MITSUBISHI PLC
DeviceType 0
addr 20
BitNo 5
Example 2: When accessing to M20 of MITSUBISHI PLC
20 ÷ 16 = 1 ... 4
DeviceType 6
addr 1
BitNo 4
*lpAddr IP address shown as a string of characters separated by dots
Example:“192.168.XXX.XXX”
• Return values
Success TRUE
Failure FALSE
Error details Get using HKEtn_GetLastError ().
Read Bits from Internal Memory
int HKEtn_ReadInternalBitMemory(int *lpOnFlag,int DeviceType,DWORD addr,int
BitNo,char *lpAddr)
This function is retained until data is transferred from the V7 series.
• Parameters
*IpOnFlag Returns the bit status. 0: OFF 1: ON
DeviceType 0: $u 1: $s
addr Top memory address to be read
BitNo Bit number to be read
*lpAddr IP address shown as a string of characters separated by dots
Example: “192.168.XXX.XXX”
• Return values
Success TRUE
Failure FALSE
Error details Get using HKEtn_GetLastError ().
