5-102 18. KEYENCE PLC
18. KEYENCE PLC
Available PLCs
*1 To connect KZ-24, 300 via RS-232C, select [KZ24/300CPU] for the PLC type on the V-SFT
editor.
*2 To connect KZ-10, 24 via RS-232C, select [KV10, 24CPU] for the PLC type on the V-SFT editor.
Select PLC Type PLC Unit/Port Connection
KZ series link
KZ300
KZ350
KZ-L2
Port 1
RS-232C [Wiring Diagram 1]
Port 2
RS-232C [Wiring Diagram 2]
RS-422 [Wiring Diagram 6]
KZ-A500
CPU
KZ-A500
CPU modular port
RS-232C [Wiring Diagram 3]
RS-422
KEYENCE’s cable “KZ-C20”
+
Hakko Electronics’ cable
“MB-CPUQ”
Mistubishi A series link KZ-L10
Port 1
RS-232C [Wiring Diagram 4]
Port 2
RS-232C [Wiring Diagram 2]
RS-422 [Wiring Diagram 6]
KZ/KV series
CPU
KZ-10, 16, 24
*1
, 40, 80,
300, 350
KV series
*2
CPU modular port
RS-232C [Wiring Diagram 5]
or
KEYENCE’s cable
“OP-26487”
+
Connector “OP-26485”
RS-422
KEYENCE’s cable “KZ-C20”
+
Hakko Electronics’ cable
“MB-CPUQ”
KZ24/300
CPU
KZ-24, 300
*1
CPU modular port
RS-232C [Wiring Diagram 5]
or
KEYENCE’s cable
“OP-26487”
+
Connector “OP-26485”
KV10/24
CPU
KV-10, 24
*2
CPU modular port
KV-700
CPU
KV-700 CPU modular port
