5-130 28. Telemecanique PLC
28. Telemecanique PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series is as follows:
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
Select PLC Type PLC Connection
TSX Micro TSX Micro RS-485 [Wiring Diagram 1]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 9600 bps 9600 bps
Connection – Multi-Link (fixed)
Parity Odd Odd
Transmission code
Data length 8 (fixed) 8
Stop bit 1 1
Memory TYPE Remarks
MW (memory word) 0
KW (constant word) 1
M (bit memory) 2
