5-50 7. YASKAWA PLC
7. YASKAWA PLC
Available PLCs
* Other PLCs can also be connected with Memobus.
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series is as follows:
Memobus
Select [TYPE 1] or [TYPE 2] for [Trans. Mode] in the [Comm. Parameter] dialog of the
V-SFT editor.
Select PLC Type PLC Unit/Port Connection
memobus
GL60 series
JAMSC-IF60
JAMSC-IF61
JAMSC-IF611
RS-232C [Wiring Diagram 1]
JAMSC-IF612
JAMSC-IF613
RS-422 [Wiring Diagram 5]
GL120, GL130 series
Memobus port on the
CPU module
RS-232C [Wiring Diagram 1]
JAMSC-120NOM27100 RS-422 [Wiring Diagram 6]
PROGIC-8 PORT2 on the CPU unit RS-232C [Wiring Diagram 2]
CP9200SH/MP900
CP9200SH CP-217IF
RS-232C [Wiring Diagram 3]
[Wiring Diagram 4]
RS-422 [Wiring Diagram 7]
MP920
MP930
Memobus port on the
CPU module
RS-232C [Wiring Diagram 1]
217IF
RS-232C [Wiring Diagram 3]
RS-422 [Wiring Diagram 8]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 19200 bps 19200 bps
Port 1 1
Parity Even Even
Transmission code
Data length 8-bit RTU (fixed) −
Stop bit 1 1
Error check CRC (fixed) −
Port delay timer 0 (fixed) −
PLC Model V7 Setting Contents
GL60 series, PROGIC-8 TYPE 1 Special binary code
GL120/130 series TYPE 2 Standard binary code
