Hakko Electronics Monitouch V7 - V712;V712 I External View and Dimensions

1-16 5. Dimensions and Panel Cut-out
V712/V712i External View and Dimensions
(Unit: mm)
SYSTEM
F1
F2 F3
F4
F5 F6 F7
POWER
CN5
MEMORY
CN6
CF
PRINTERMJ2MJ1
CN1
LAN
100-240VAC
L N
326.4
259.6
8
312
312
245.2
313
+0.5
-0
+0.5 -0
246.2
72
245.2
63.8
See operating or maintenance
instruction for type of battery
to be used.
Battery replacement.
• Side View • Front View
• Panel Cut-out Dimensions
• Rear View • Bottom View
