JW Series: Link Unit Switch Setting
Baud Rate: 19200 bps
JW100/70H COM Port, JW20 COM Port:
System Memory Setting
The settings for communications with the V7 series should be made at the system memory as shown
below.
• JW-70CU/100CU, JW70CUH/100CUH, JW22CU
• JW-32CUH/33CUH
- Communication port 1
- Communication port 2
Switch Setting Contents
SW0 4 Command mode
SW1 1 Station address (lower half)
SW2 0 Station address (upper half)
SW3-1 OFF Not used
SW3-2 ON 4-wire system
SW3-3 OFF Not used
SW3-4 ON Even parity
SW4 0 Baud rate
0: 19200 1: 9600 2: 4800 3: 2400 4: 1200 5: 600
SW7 ON Terminating resistance provided
System Memory Setting Contents
#236 30H Stop bit: 2 bits, parity: even, baud rate: 192000
#237 01H Port
System Memory Setting Contents
#234 30H Stop bit: 2 bits, parity: even, baud rate: 192000
#235 01H Port
System Memory Setting Contents
#236 30H Stop bit: 2 bits, parity: even, baud rate: 192000
#237 01H Port
