5-108 19. LG PLC
19. LG PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series is as follows:
MASTER-K10/60/200
MASTER-K500/1000
*1 For signal level RS-422, baud rate is fixed to 9600 bps.
Select PLC Type PLC Connection
MASTER-K10/60/200 K10/60/200 RS-232C [Wiring Diagram 1]
MASTER-K500/1000 K500/1000
RS-232C [Wiring Diagram 2]
RS-422 [Wiring Diagram 5]
MASTER-KxxxS K200S/K300S/K1000S CPU port RS-232C [Wiring Diagram 3]
MASTER-KxxxS CNET K4F-CUEA
RS-232C [Wiring Diagram 4]
RS-422 [Wiring Diagram 6]
GLOFA CNET G4L-CUEA
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 9600 bps (fixed) −
Parity None (fixed) −
Transmission code
Data length 8 (fixed) −
Stop bit 1 (fixed) −
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 19200 bps
*1
19200 bps
Parity None (fixed) −
Transmission code
Data length 8 (fixed) −
Stop bit 1 (fixed) −
