5-76 11. Allen-Bradley PLC
PLC-5 Series: Switch Setting
1785-KE
SW1 (Protocol)
SW2 (Port)
Set the port number of 1785-KE. (This port should not be duplicated in the network.)
SW3 (Network link communication speed)
Adjust to the settings of the network you are using.
SW4 (Spare)
No Setting Contents
1ON
BCC, even, no2OFF
3OFF
4 ON Duplicated message unacceptable
5 OFF Handshaking signal ignored
6 ON Execution of diagnosis command
No Setting Contents
1ON
1st digit (octal)
2ON
3ON/OFF
2nd digit (octal)4ON/OFF
5ON/OFF
6ON/OFF
3rd digit (octal)7ON/OFF
8ON/OFF
No Setting Contents
1ON
Data highway (57.6 kbps)
2ON
3ON
Link communication speed (19.2 kbps)4ON
5ON
6 ON Local/remote selection
No Setting Contents
1OFF
For extension, always OFF
2OFF
3OFF
4OFF
