1-12 4. Specifications
Drawing Environment
Display Function Specifications
* Refer to the Reference Manual (Operation) for HK fonts.
Item Specifications
Drawing Method Exclusive drawing software
Drawing Tool Name of exclusive drawing software: V-SFT (Ver. 2.00 and later)
Personal computer: Pentium II 450 MHz or above recommended
OS: Windows98/Me/NT Ver. 4.0/2000/XP
Capacity of hard disk required: Free space of approx. 460 Mbyte or more
(For minimum installation: approx. 105 Mbyte)
Display: Resolution 800 × 600 or above recommended
Item Specifications
Display Language* Japanese English/
European
Chinese Chinese
(Simplified)
Korean
Characters 1/4-size
1-byte
ANK code Latin 1 ASCII code ASCII code ASCII code
2-byte
16-dot
JIS #1, #2 level −−−− Chinese
Chinese
(simplified)
Hangul
(without Kanji)
2-byte
32-dot
JIS #1 level −−−− −−−− −−−− −−−−
Character Size 1/4-size: 8 × 8 dots
1-byte: 8 × 16 dots
2-byte: 16 × 16 dots or 32 × 32 dots
Enlarge: W: 1 to 8 times, H: 1 to 8 times
Number of
Displayable
Characters
Resolution 640 × 480 800 × 600
1/4-size 80 columns × 60 lines 100 columns × 75 lines
1-byte 80 columns × 30 lines 100 columns × 37 lines
2-byte 40 columns × 30 lines 50 columns × 37 lines
Characters
Properties
Display properties: Normal, reverse, blink, bold, shadow
Colors: 32,768 colors + blink 16 colors (V708C: 128 colors + blink 16 colors)
Graphics Lines: Line, continuous line, box, parallelogram, polygon
Circles: Circle, arc, sector, ellipse, elliptical arc
Others: Tile patterns
Graphic Properties Line types: 6 (thin, thick, dot, chain, broken, two-dot chain)
Tile patterns: 16 (incl. user-definable 8 patterns)
Display properties: Normal, reverse, blink
Colors: 32,768 colors + blink 16 colors (V708C: 128 colors + blink 16 colors)
Color selection: Foreground, background, boundary (line)
