14. TOSHIBA MACHINE PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series is as follows:
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
Select PLC Type PLC Unit/Port Connection
TC200
TC200
Port on the CPU unit
RS-232C [Wiring Diagram 1]
TCCMW
TCCMO
TCmini −
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 9600 bps 9600 bps
Port 1 1
Memory TYPE Remarks
D (register 1) 0
B (register 2) 1
X (input relay) 2 XW as word device
Y (output relay) 5 YW as word device
R (temporary storage) 6 RW as word device
G (extension temporary storage 1) 7 GW as word device
H (extension temporary storage 2) 8 HW as word device
L (latch relay) 9 LW as word device
S (shift register) 10 SW as word device
E (edge relay) 11 EW as word device
P (timer counter current value) 12
V (timer counter set value) 13
T (timer) 14 TW as word device
C (counter) 15 CW as word device
A (special auxiliary relay) 16 AW as word device
