6. YOKOGAWA PLC 5-45
Connection to PLCs
6. YOKOGAWA PLC
Available PLCs
*1 The CPUs that can be connected directly to the programming tool port on the CPU module are
“F3SP21-0N,” “F3SP25-2N,” “F3SP35-5N,” “F3SP28-3N,” “F3SP38-6N,” “F3SP53-4H” and
“F3SP58-6H.”
*2 When the link unit “F3LC01-1N” is used, the communication setting and available memory are
the same as those for “FA-500.” However, B (common register) cannot be used.
Select PLC Type CPU Unit/Port Connection PLC2Way
FA500 FA500
LC01-0N RS-232C [Wiring Diagram 1]
LC02-0N
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 3]
FA-M3 FA-M3
Programming tool port
on the CPU module
*1
YOKOGAWA’s ladder transfer
cable “KM11-2N”
F3LC01-1N
*2
RS-232C [Wiring Diagram 2]
F3LC11-1N
F3LC11-2N RS-422 [Wiring Diagram 3]
FA-M3R FA-M3 R
Programming tool port
on the CPU module
*1
YOKOGAWA’s ladder transfer
cable “KM11-2N”
F3LC12-1F RS-232C [Wiring Diagram 2]
