5-86 13. TOSHIBA PLC
13. TOSHIBA PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series is as follows:
• PLC Transmission Parameter Setting
When setting parameters on the PLC, use the T series programmer and enter the
following data for system information “7. COMPUTER LINK.”
Select PLC Type PLC Unit/Port Connection
T series T series Computer link port on CPU RS-422 [Wiring Diagram 1]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 19200 bps 19200 bps
Port 01 1
Parity Odd Odd
Transmission code
Data length 8 8
Stop bit 1 1
Station number 1
Baud rate 19200 bps
Parity Odd
Data length 8 bits
Stop bit 1 bit
