18. KEYENCE PLC 5-103
Connection to PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series is as follows:
KZ Series Link
Set the port with the port setting switch, the terminating resistance with terminator, and the
baud rate/data bit/parity/stop bit with SET B DIP switches.
KZ-A500 CPU (CPU Modular Port)
*1 For signal level RS-422, baud rate is fixed to 9600 bps.
Mistubishi A Series Link (Link Unit KZ-L10)
Set the port with the port setting switch, the terminating resistance with terminator, and the
baud rate/data bit/parity/stop bit with SET B DIP switches. For more information, refer to
the instruction manual for KZ-L10.
Item Setting on PLC V7 Comm. Parameter Setting
Port 0 0
Baud rate 19200 bps 19200 bps
Parity Even Even
Transmission code
Data length 7 (ASCII) 7
Stop bit 2 2
Terminating resistance ON for RS-422 −
Item Setting on PLC V7 Comm. Parameter Setting
Port 0 0
Baud rate 9600 bps 9600 bps
*1
Parity Odd Odd
Transmission code
Data length 8 8
Stop bit 1 1
Terminating resistance ON for RS-422 −
Item Setting on PLC V7 Comm. Parameter Setting
Port 0 0
Baud rate 19200 bps 19200 bps
Parity Even Even
Transmission code
Data length 7 7
Stop bit 1 1
Terminating resistance ON for RS-422 −
