Hakko Electronics Monitouch V7 - 5. Dimensions and Panel Cut-out

1-14 5. Dimensions and Panel Cut-out
5. Dimensions and
Panel Cut-out
V708/V708i External View and Dimensions
(Unit: mm)
24VDC
- +
F1
F2
F3
F4
F5
F6
F7
SYSTEM
POWER
LAN
CN1
MJ1
MJ2
PRINTER
CF
CN5
MEMORY
CN6
165
24.3
220
220.5
+0.5 -0
165.5
66.1
165
233
178
220
6.6
+0.5
-0
See operating or maintenance
instruction for type of battery
to be used.
Battery replacement.
• Side View • Front View
• Panel Cut-out Dimensions
• Rear View • Bottom View
