Hakko Electronics Monitouch V7 - V710;V710 I External View and Dimensions

1
5. Dimensions and Panel Cut-out 1-15
Hardware Specifications
V710/V710i External View and Dimensions
(Unit: mm)
100-240VAC
L N
F1
F2
F3
F4
F5
F6
F7
SYSTEM
POWER
LAN
CN1
MJ1 MJ2
PRINTER
CF
CN5
MEMORY
CN6
289
+0.5
-0
216.2
+0.5 -0
288.0
288.0
215.2
35.2
215.2
303.8
231
72
8
See operating or maintenance
instruction for type of battery
to be used.
Battery replacement.
• Side View • Front View
• Panel Cut-out Dimensions
• Rear View • Bottom View
