5-62 9. FUJI PLC
Wiring
Wiring diagrams with the PLC are shown below.
RS-232C
Wiring Diagram 1
Wiring Diagram 2
V7 (CN1)
D-sub 25pin(Male: )
FG
RD
RS
CS
SG
1
3
4
5
7
SD
RD
SD 2
RS
CS
DR
PLC
2
3
4
5
6
SG
CD
7
8
D-sub 25pin(Male: )
* Use shielded twist-pair cables.
D-sub 25-pin (male)
D-sub 25-pin (male)
V7 (CN1)
D-sub 25pin(Male: )
FG
RD
RS
CS
SG
1
3
4
5
7
RD
SD
SD 2
CTS
RTS
NJ-B16
2
3
4
5
SG 7
D-sub 15pin(Male: )
* Use shielded twist-pair cables.
D-sub 25-pin (male)
D-sub 15-pin (male)
