5
9. FUJI PLC 5-63
Connection to PLCs
RS-485
Wiring Diagram 3
RS-422
Wiring Diagram 4
V7 (CN1)
D-sub 25pin(Male: )
FG
+SD
- SD
+RD
- RD
1
12
13
24
25
SDA
SDB
SG 7
RDA
RDB
SG
PLC
* Use shielded twist-pair cables.
D-sub 25-pin (male)
V7 (CN1)
D-sub 25pin(Male: )
FG
+SD
- SD
+RD
- RD
1
12
13
24
25
+
-
PLC
SG
SG 7
* Use shielded twist-pair cables.
D-sub 25-pin (male)
