9. FUJI PLC 5-59
Connection to PLCs
FLEX-PC CPU Port
Connect to the CPU port. Communication parameters for the V7 series are automatically
set.
FLEX-PC COM (T) (NJ Computer Link) Toyota Version
MICREX-F Series, FLEX-PC Series: Switch Setting
MODE switch: RS-232C: 1 RS-485: 3
RS-485 Port Setting SW: “0” for both ×10, ×1
RS-485 terminating resistance: ON
Character switches
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 19200 bps 19200 bps
Port 0 0
Parity Even Even
Transmission code
Data length 7 7
Stop bit 2 2
No Setting Contents
8 ON Switch Setting
7ONWith parity
6ONEven
5ON7 bits
4ON1 bit
3ON
Same as that set on V7 (normally 19200 bps)2ON
1OFF
