5-82 12. GE Fanuc PLC

12. GE Fanuc PLC

Available PLCs

Communication Setting

The recommended communication parameter settings of the PLC and the V7 series is as

follows:

90 Series

90 Series SNP-X

Select PLC Type PLC Unit/Port Connection

90 series Series 90-30

Programmable

coprocessor (PCM)

RS-232C [Wiring Diagram 1]

RS-485 [Wiring Diagram 2]

90 series

(SNP-X)

Series 90 micro

Series 90-30

CPU port RS-485 [Wiring Diagram 3]

Item Setting on PLC V7 Comm. Parameter Setting

Baud rate 19200 bps 19200 bps

Port 01 (“0” for ×10, “1” ×1) 1

Parity Odd Odd

Transmission code

Data length 8 8

Stop bit 1 1

Functions Host link function (fixed) −

Response delay time 0 (fixed) −

Timeout None (fixed) −

ASCII/HEX HEX (fixed) −
