5-122 24. YAMATAKE PLC
24. YAMATAKE PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series is as follows:
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
Select PLC Type PLC Unit/Port Connection
MX series MX200/MX50 ASCII connector RS-232C [Wiring Diagram 1]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 9600 bps 9600 bps
Port 1 1
Parity Even Even
Transmission code
Data length 8 8
Stop bit 1 1
Memory TYPE Remarks
R (data register) 0
M (auxiliary relay) 1
L (latch relay) 2
X (input relay) 3
Y (output relay) 4
TP (timer/current value) 5
TS (timer/setting value) 6
CP (counter/current value) 7
CS (counter/set value) 8
T (timer/contact) 9
C (counter/contact) 10
P (link register) 11
