5-98 16. SHINKO PLC
16. SHINKO PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series is as follows:
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
Only D register of SELMART is available. No other devices can be used.
Be sure to note the above though the setting on the V-SFT editor is possible.
Select PLC Type PLC Unit/Port Connection
SELMART SELMART-100 and later Version O1M2-UCI-6
RS-232C [Wiring Diagram 1]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 19200 bps 19200 bps
Parity Even Even
Transmission code
Data length 7 (ASCII) 7
Stop bit 1 1
Sumcheck Provided (fixed) −
Memory TYPE Remarks
D (data register) 0
