5-64 10. KOYO PLC
10. KOYO PLC
Available PLCs
Select PLC Type PLC Unit/Port Connection
SU/SG
SU-5/5E/6B/5M/6M U01-DM
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 3]
SU-5E/6E
Universal port 1 on CPU
RS-232C [Wiring Diagram 1]
SU-5M/6M
RS-422 [Wiring Diagram 7]
Universal port 3 on CPU RS-485 [Wiring Diagram 8]
Universal port 2 on CPU RS-232C
KOYO’s programmer
connecting cable S-30JG-E
+
KOYO’s conversion connector
S-15CNJ
SZ-4
PORT2 on CPU
(universal
communication port)
SZ-4M
PORT2 on CPU
(universal
communication port)
RS-232C
KOYO’s programmer
connecting cable S-30JG-E
+
KOYO’s conversion connector
S-15CNJ
+
KOYO’s conversion connector
S-15HCNP1
SG-8
G01-DM
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 4]
Port on CPU
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 4]
PZ3
Universal
communication port on
the CPU unit
RS-232C [Wiring Diagram 2]
RS-485 [Wiring Diagram 6]
SR-T SR-6T (Toyota version)
U01-DM
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 3]
G01-DM
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 4]
SR-T
(K protocol)
SR-1T (Toyota version)
Terminal block on the
CPU unit
RS-422 [Wiring Diagram 5]
(To be continued)
