9. FUJI PLC 5-61
Connection to PLCs
FLEX-PC Series, FLEX-PC CPU Port
FLEX-PC COM (T) (NJ Computer Link) Toyota Version
Standard Memory Toyota Version TYPE Remarks
D (data register) D 0
W (link register) R 1
M (internal relay) M 2 WM as word device
L (latch relay) K 3 WL (WK) as word device
X (input relay) X 4 WX as word device
Y (output relay) Y 5 WY as word device
R (file register) W 6
TN (timer/current value) TN 7
CN (counter/current value) CN 8
T (timer/contact) T 9
C (counter/contact) C 10
WS (step relay) Not provided 11
Memory TYPE Remarks
D (data register) 0
R (link register) 1
M (internal relay) 2 WM as word device
K (latch relay) 3 WK as word device
X (input relay) 4 WX as word device
Y (output relay) 5 WY as word device
W (file register) 6
TN (timer/current value) 7
CN (counter/current value) 8
T (timer/contact) 9
C (counter/contact) 10
Z (special register) 12
V (special relay) 13 WV as word device
