5
1. MITSUBISHI PLC 5-3
Connection to PLCs
FX Series
*1 For more information of V-MDD (dual port interface), refer to page 5-17.
Select PLC Type CPU Unit/Port Connection PLC2Way
FX series CPU
FX1/2 Tool port
*1
RS-232C
Hakko Electronics’ cable
“PC-CX24A”
RS-422
Hakko Electronics’ cable
“MB-CPUQ”
or
[Wiring Diagram 7]
FX0N
Tool port
*1
RS-422
Hakko Electronics’ cable
“MI4-FX”
or
Hakko Electronics’ cable
“MB-CPUQ”
+
MITSUBISHI’s conversion
cable “FX-20P-CADP”
FX2N series CPU
FX2N/1N
FX2NC
FX1S series CPU FX1S
FX series link
(A Protocol)
FX2N
FX2N-232-BD RS-232C [Wiring Diagram 3]
FX2N-485-BD RS-485 [Wiring Diagram 8]
FX2N-422-BD
RS-422 Hakko Electronics’
cable “MI4-FX”
FX1N
FX1S
FX1N-232-BD RS-232C [Wiring Diagram 3]
FX1N-485-BD RS-485 [Wiring Diagram 8]
FX1N-422-BD
RS-422 Hakko Electronics’
cable “MI4-FX”
FX0N
FX0N-232ADP RS-232C [Wiring Diagram 4]
FX0N-485ADP RS-485 [Wiring Diagram 8]
FX2NC
FX0N-232ADP RS-232C [Wiring Diagram 4]
FX0N-485ADP RS-485 [Wiring Diagram 8]
